GTX Series GTX2971R

G-Series GTX2971R The Next Generation in Turbocharging Technology

Information

  • Horsepower: 340 - 560CV
  • Displacement: 1.8L - 3.0L
  • Features Original Gtx Comp Wheel Aerodynamics
  • 54mm turbocharger compressor option
  • Available in 84 and 90 trim turbine options
  • ☎ Call: +39 071715693
  • ✉ Send e-mail: info@saito.it
  • 🌏 Worldwide delivery!

Description

Super Core Reference Data Compressor Turbine
Super Core PN CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
836041-5002S 836013-0002 54mm 71mm 58 0.60 57mm 52mm 84
836041-5003S 836013-0003 54mm 71mm 58 0.60 57mm 54mm 90
Notes: Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim
Super Core and Turbine Kit Sold Separately 827690-0006 0.64 T25 5-Bolt Wastegated N 84
827690-0007 0.86 T25 5-Bolt Wastegated N 90
740902-0048 0.61 V-Band V-band Free Float N 84
740902-0051 0.61 V-Band V-band Free Float N 90
740902-0047 0.83 V-Band V-band Free Float N 84
740902-0050 0.83 V-Band V-band Free Float N 90
740902-0046 1.01 V-Band V-band Free Float N 84
740902-0049 1.01 V-Band V-band Free Float N 90



About Garrett Performance GTX Series Turbochargers

Garrett Performance GTX Series turbochargers are designed specifically for the hard-core enthusiast who wants optimal performance. The forged fully-machined billet aluminum compressor wheels feature next generation aerodynamics that provide a larger horsepower range and maximize boost response.

Ported shroud compressor housings increase surge resistance and provide reliable, continuous power throughout the power band. A dual ceramic ball bearing cartridge prolongs the lifespan and improves shaft balance. The water cooled CHRA keeps housing temperatures to a minimum. The turbine wheel is constructed from Inconel, a Super Alloy that maintains strength during prolonged exposure to high exhaust gas temperatures.

Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. GTX Series turbochargers are used by today’s top motorsports teams and are ready to boost you to the podium or wherever your destination may be.
