GTX Series GTX4720R GEN II 88mm

GTX Series GTX4720R GEN II: the most powerful Large-Frame Turbocharger

Information

  • Horsepower: 1025 - 1950CV
  • Displacement: 2.5L - 10.0L
  • Gen II compressor wheel aerodynamics
  • 88mm Compressor inducer | 120mm compressor exducer
  • 93mm Turbine inducer | 84mm turbine exducer
  • 9% Increased compressor flow
  • Larger .88 a/r compressor housing volute
  • GTX4720R features a 120mm comp exducer ( + 2 mm) and has 30% lower inertia compared to GTX4718R
  • Supercore and turbine housing sold separately
  • Compatible with gt and gtx turbine housings
  • 88mm Supercore pn: 851285-5015S
  • ☎ Call: +39 071715693
  • ✉ Send e-mail: info@saito.it
  • 🌏 Worldwide delivery!

Description

GTX4720R GEN II Compressor Turbine
HP: 1025-1950 Disp: 2.5L-10.0L Inducer Exducer Trim A/R Inducer Exducer Trim
Supercore PN
851285-5013S 76mm 120mm 41 0.88 93mm 84mm 82
851285-5014S 80mm 120mm 45 0.88 93mm 84mm 82
851285-5015S 88mm 120mm 54 0.88 93mm 84mm 82
Turbine Kits: GTX47 PN A/R Inlet Outlet Wastegate Divided
Interchangeable with GT|GTX 4708 4709
4718 4720 Supercores
761208-0009 0.96 T6 V-Band Free Float N
761208-0010 1.08 T6 V-Band Free Float N
761208-0011 1.23 T6 V-Band Free Float N
761208-0012 1.39 T6 V-Band Free Float N



About Garrett Performance GTX Series Turbochargers

Garrett GTX Series turbochargers are designed specifically for the hard-core enthusiast who wants optimal performance. The forged fully-machined billet aluminum compressor wheels feature next generation aerodynamics that provide a larger horsepower range and maximize boost response.

Ported shroud compressor housings increase surge resistance and provide reliable, continuous power throughout the power band. A dual ceramic ball bearing cartridge prolongs the lifespan and improves shaft balance. The water cooled CHRA keeps housing temperatures to a minimum. The turbine wheel is constructed from Inconel, a Super Alloy that maintains strength during prolonged exposure to high exhaust gas temperatures.

Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. GTX Series turbochargers are used by today’s top motorsports teams and are ready to boost you to the podium or wherever your destination may be.
