Information
- Horsepower: 825 - 1625CV
- Displacement: 2.0L - 10.0L
- Gen II compressor wheel aerodynamics
- 80mm compressor inducer | 109mm compressor exducer
- 93mm turbine inducer | 84mm turbine exducer
- 15% Increased flow
- Larger .88 a/r compressor housing volute
- GTX4709R features a 109mm comp exducer ( + 1mm) and has 39% lower inertia compared to GTX4708R
- Supercore and turbine housing sold separately
- Compatible with gt and gtx turbine housings
- 80mm Supercore part number: 851285-5012S
- ☎ Call: +39 071715693
- ✉ Send e-mail: info@saito.it
- 🌏 Worldwide delivery!
Description
| GTX4709R GEN II | Compressor | Turbine | ||||||
|---|---|---|---|---|---|---|---|---|
| HP: 825-1625 Disp: 2.0L-10.0L | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | |
| Supercore | PN | |||||||
| 851285-5011S | 76mm | 109mm | 49 | 0.88 | 93mm | 84mm | 82 | |
| 851285-5012S | 80mm | 109mm | 54 | 0.88 | 93mm | 84mm | 82 | |
| Turbine Kits: GTX47 | PN | A/R | Inlet | Outlet | Wastegate | Divided | ||
| Interchangeable with GT|GTX 4708 4709 4718 4720 Supercores |
761208-0009 | 0.96 | T6 | V-Band | Free Float | N | ||
| 761208-0010 | 1.08 | T6 | V-Band | Free Float | N | |||
| 761208-0011 | 1.23 | T6 | V-Band | Free Float | N | |||
| 761208-0012 | 1.39 | T6 | V-Band | Free Float | N | |||
About Garrett Performance GTX Series Turbochargers
Garrett GTX Series turbochargers are designed specifically for the hard-core enthusiast who wants optimal performance. The forged fully-machined billet aluminum compressor wheels feature next generation aerodynamics that provide a larger horsepower range and maximize boost response.
Ported shroud compressor housings increase surge resistance and provide reliable, continuous power throughout the power band. A dual ceramic ball bearing cartridge prolongs the lifespan and improves shaft balance. The water cooled CHRA keeps housing temperatures to a minimum. The turbine wheel is constructed from Inconel, a Super Alloy that maintains strength during prolonged exposure to high exhaust gas temperatures.
Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. GTX Series turbochargers are used by today’s top motorsports teams and are ready to boost you to the podium or wherever your destination may be.
